Oct 28, 2009

Sound Disappear After Restart - Part 2

Here is the second method for most Compaq CQ which the sound disappear after restart.
this solution regarding to audio works after installing batch file KB835221.

Download the CQaudiosolution: (Link fixed on March 22 2015)


Inside the RAR file there is an audio patch and devcon patch file. Devcon file will solve issue with KB835221 (missing PnP function id). Follow the given instruction below

a) You must install two patches first from Microsoft: KB835221 (UAA version 1.0) and then kb888111 (UAA update version 1.0a)

b) Install the IDT HD Audio driver (you can use your Vista driver from HP site as well)
c) Extract CQAudioSolution.rar you've downloaded
d) Extract devcon.exe self-extracter from Devcon folder extracted in c)
e) Copy devcon.exe from extracted folder in (d) to C:\WINDOWS\SYSTEM32
f) Run Audio path from extracted Audio Path folder in c)
g) Restart
h) You should be able play sound with IDT HD Audio after restart.

However, in Device Manager, there is a exclamation icon on "Audio Device on High Definition Audio Bus". This is installed by KB835221 patch. Just ignore it. The CQAudioSolution will make sure that there is no more issue with missing IDT HD Audio when restarting after installing the IDT HD Audio driver.

Credits:
t3chn0m4nc3r

Oct 22, 2009

4 unknown devices in Windows 7 RTM 64 on dv7

before proceed with the steps to solve your problems make sure you check the ID, the ID for dv7 i have is ACPI/HPQ0004 so it is the:

ProtectSmart Hard Drive Protection
Download

this will solve 3 unknown device and the other one left is:

HDD protection feature:
Download

Oct 21, 2009

Unknown Base System Device Windows 7 in Compaq CQ

So if you finish installing windows 7 you'll find most of the drivers installed automatically but if you see unknown base device with yellow marks on device manager it is the card reader driver:

Download

right click and select run as administrator. install and done!

Oct 20, 2009

BIOS recovery method for Compaq

There are two special keys Windows Key+B or up key+down key+left key+right key
to use for this recovery processes.

Below are the step by step procedures to perform the recovery

1) Make sure power is off

2) Make sure AC Adapter is plugged in.

3) Plug in a USB floppy drive with floppy disk that contains only one binary file (for example: 68ytt.bin for nx6125/nx6115, 68tt2.bin for nx6325/nx6315, or the correct binary file for your series of HP Compaq Commercial notebook ).

4) Press Windows Key+B (or all 4 directional keys)

5) Press power button (to power on the system)

6) Don't release the Windows key+B (or 4 directional keys) until floppy is turning and running for a period of time.

7) If floppy is turning and running for a period of time then you can release the keys and it must be doing the recovery already.

8) When it is doing the recovery, you'll notice that num-lock LED is constantly flashing.

9) When it is finished flashing the bios, the system will reboot itself.

10)Don't do anything right now and wait until HP logo shows up because it will do several reboot to update KBC ( Key Board Controller )....

11)Voila! you've got your system updated with newest BIOS.... when see HP logo press F10--restore to default--check the system info for BIOS version.

If system cannot be resurrected, it means that the BB ( Boot Block ) inside the ROM chip has been destroyed. The only way to reflash the BIOS is to remove the ROM chip from the motherboard and use an external BIOS ROM programmer to program the BIOS content again.

How to get the System BIOS binary file.
The easiest ways is to get a ROMPaq version of the System BIOS for your notebook and following the steps below;

1. Double click the downloaded SPXXXxx.exe file.

2. File Download – Security Warning window pops up and then Click Save.

3. Select the location where you want to save this ROMpaq file.

4. After download complete, select Open Folder

5. Double click SPXXXXX.exe to bring up Open File – Security Warning window and then select Run.

6. Follow the on-screen instructions to generate a folder to hold all the files.

7. Open this folder and locate a WinZip file. Inside this zip file, you need to extract all the files and the Rom.bin is the binary file you need for this recovery process.

compile by: Clinton Tam
